Wecon 60 I/O PLC : LX5V-3624MT
- Fastest: 0.01us~0.03us execution speed;
- Support larger program capacity: 48,000 steps;
- Supports the highest baud rate: 921600;
- Supports 8-channel external interrupt and supports rising and falling edges;
- Support 100us high speed timer interrupt;
- Supports up to 100 high-speed counting interrupts;
- Supports E-CAM;
- Supports electronic gear;
- Supports efficient and stable PID and CCPID auto-tuning;
- Supports IO module and LX 3V series analog module;
- Support LX 3V series BD modules (Communication BD module is not supported now).
| LX5V Model | I/O | Output Type | Pulse Counter | E-CAM | Pulse Output | RS485 | BD Board | Module | Power Supply | Ethernet |
| LX5V-2424MT-A(D/AN/DN) | 24/24 | Transistor | 8 | YES | 8 | 2 | 2 | YES | AC(DC) | Optional |
| LX5V-3624MT-A(D/AN/DN) | 36/24 | Transistor | 8 | YES | 8 | 2 | 2 | YES | AC(DC) | Optional |
GENERAL
| Item | LX5V Series |
| Running Mode | Round Scan/ Interrupt |
| Programming | Instruction List/ Ladder |
| Total Instructions | Basic Instructions: 29 / Application Instructions: 170 |
| Execute time | Basic Instructions: 0.01-0.03us |
| System Storage | 512KB |
| Download/ Monitoring | Serial Programming Cable (Serial port) / Micro USB |
| High Speed Counter Interrupt | 100 Channels |
| High Speed Pulse Output | Transistor: 8 channels / 200K |
| External Input Interrupt | X0-X7 supports both rising and falling edges |
| Timer Interrupt | 100 Channels, Interruption time (min): 0.1ms |
| High Speed Input Single | 8 Channels 150KHz |
| High Speed Input AB Phase | 8 channel 100KHz, frequency modes:1/2/4 times |
| Holding Addresses | Adjusted by software |
| Storage | FLASH |
| Filter | For all X input terminals |
| Serial Port | COM1: RS422 or RS485 COM2: RS485 |
| Temperature | Working Temperature: 0 ~ 55℃ / Storage Temperature: 0 ~ 70℃ |
| Humidity | 35~ 85%RH (Without condensation) |
| Shock Resistance | JIS C 0040 Standard |
| Influence Immunity | Meet the IEC61000-4-4 and GB/T 17626.4 standard: Noise voltage amplitude 1KVP-P, pulse width 10us, period 0.3 s, edge time 5ns, duration 1min. |
| USB Supply | Use for upgrading firmware, downloading ladder diagram |
POWER SUPPLY
| Item | AC | DC |
| Power Supply | AC 85~265V 50 ~ 60Hz | DC 24V±10% |
| Power Outage Time | 10ms | 10ms |
| Power Fuse | 250V 3.15A | 250V 3.15A |
| Rush Current | <15A 5ms / AC 100V; <30A 5ms / AC 200V | <15A 1ms / DC 24V |
| Power Consumption | <60W | <30W |
| Power Output | DC 24V 700mA | <30w(Not include the external power supply for modules) |
OUTPUT
| Item | Relay | Transistor | |
| Output Mode | — | NPN | |
| Input Power Supply | DC 24V | DC 24V | |
| Output Circuit | <AC 250V or <DC 30 | DC 5~30V | |
| COM Port Current | — | <0.1mA (DC 30V) | |
| Insulation | Mechanistic | Optical Coupling | |
| Leak current | — | 0.1mA / DC 30V | |
| Min. Load | — | DC5V 2mA | |
| Max. Load | Resistive | 2A point 8A COM port | 0.5A point 0.8A COM port 0.3A HSPO point |
| Inductive | 80VA | 12W/DC24V 7.2W HSPO point | |
| General | 100W | 0.9W/DC 24V | |
| Response Time | <10ms | <0.2ms (Pulse output terminal: <5us) | |
Wecon 60 I/O PLC : LX5V-3624MT
PLC WECON LX5V-3624MT-A
Faster: 0.01us~0.03us execution speed; Supports larger program capacity: 48,000 steps; Supports the highest baud rate: 921600; Supports 8 channels external interrupt, and support both rising and falling edges; Supports 100us high-speed timer interrupt; Supports up to 100 high-speed counting interrupts; Supports E-CAM; Supports electronic gear; Supports efficient and stable PID and CCPID self-tuning; Supports IO module and analog module of LX 3V series; Supports BD modules of LX 3V series (Communication BD module not supported now).
