Wecon 3.5 inch HMI Standard:LEVI2035T
Model | LEVI2035T | LEVI2043T | ||
General | Screen Size | 3.5 Inch | 4.3 Inch | |
Resolution | 320*240 | 480*272 | ||
Colors | 65536 color | |||
Brightness | 330cd/m2 | 450cd/m2 | ||
Backlight Type | LED | |||
Touch Screen | High procision four-wire resistive | |||
Backlight Life Time | 50000 hours | |||
CPU | 32-bits 300MHz RISC | |||
Storage | 128M FLASH + 64M DDRAM | |||
RTC | 256KB | |||
Printer Port | Serial port Printer | |||
USB Port | USB host + USB Client | |||
SD card | — | |||
COM | COM1 | RS422/RS485 | RS422/RS485 | |
COM2 | RS232 | RS232 | ||
COM3 | — | — | ||
Power | Power | <5w< span=””> | <5w< span=””> | |
Power Supply | DC 24V ( 12~28V DC ) | |||
Allowed Power Fail | <5ms< span=””> | |||
Insulation Resistance | >20MΩ 500V DC | |||
Withstand Voltage | 500V AC < 1 minute | |||
Dimension | Shell | ABS,Black | ||
Dimension (mm) | 96.0W*81.0H*33.0D | 141.4W*85.4H*38.9D | ||
Mounting size (mm) | 91.0W*73.0H | 131.0W*79.0H | ||
Net/Gross (KG) | 0.14/0.26 | 0.23/0.39 | ||
Operate Environment | Temperature | Working Temperature : -10~60℃ ; Storage Temperature : -20~70℃ | ||
Humidity | Working Humdity : 10~90% RH ; Storage Humidity : 10~90%RH | |||
Seismic Resistance | 10~25 Hz ( X,Y,Z direction 2G/30 minutes) | |||
Cooling | Air cooling | |||
Extension | Ethernet | — | — | |
CAN | — | — | ||
TTS | — | — | ||
COM3 | — | — | ||
Protection | IP65 ( Front panel ) | |||
CE Certification | CE Marked | |||
FCC Certification | FCC Class A |
