Wecon 10.2 inch HMI economic-LEVI102ML
Model | LEVI102ML | ||
General | Screen Size | 10.2 Inch | |
Resolution | 800*480 | ||
Colors | 65536 colors | ||
Brightness | 350cd/m2 | ||
Backlight Type | LED | ||
Touch Screen | High procision four-wire resistive | ||
Backlight Life | 50,000 hours | ||
Time | |||
CPU | 32-bits 300MHz RISC | ||
Storage | 128M FLASH + 64M DDRAM | ||
USB Port | USB host + USB Client | ||
COM | COM1 | RS422/RS485 | |
COM2 | RS232 | ||
Power | Power | <5w | |
Power Supply | DC 24V ( 12~28V DC ) | ||
Dimension | Shell | PC+ABS, Cold Grey | |
Dimension (mm) | 272.0W*190.7H*41.3D | ||
Mounting size (mm) | 260.0W*179.0H | ||
Net/Gross (KG) | 1.04/1.37 | ||
Operate Environment | Temperature | Working Temperature : -10~60℃ ; Storage Temperature : -20~70℃ | |
Humidity | 10-85%RH (Non-condensing) | ||
Seismic Resistance | 10~25 Hz ( X,Y,Z direction 2G/30 minutes) | ||
Cooling | Air cooling | ||
Protection | IP65 ( Front panel ) | ||
CE Certification | CE Certification: CE marked | ||
FCC Certification | FCC Class A |
