Wecon New Style 7 inch HMI: LEVI2070D
Model | LEVI2070D | ||
General | Screen Size | 7 Inch | |
Resolution | 800*480 | ||
Colors | 65536 colors | ||
Brightness | 250cd/m2 | ||
Backlight Type | LED | ||
Touch Screen | High procision four-wire resistive | ||
Backlight Life | 50000 hours | ||
Time | |||
CPU | 32-bits 300MHz RISC | ||
Storage | 128M FLASH + 128M DDRAM | ||
USB Port | USB host + USB Client | ||
COM | COM1 | RS422/RS485 | |
COM2 | RS232 | ||
Power | Power | <5w | |
Power Supply | DC 24V ( 12~28V DC ) | ||
Dimension | Shell | PC+ABS, Cold Grey | |
Dimension (mm) | 201.0W*147.0H*39.0D | ||
Mounting size (mm) | 192.0W*138.0H | ||
Net/Gross (KG) | 0.5/0.74 | ||
Operate Environment | Temperature | Working Temperature : -10~60℃ ; Storage Temperature : -20~70℃ | |
Humidity | 10-85%RH (Non-condensing) | ||
Seismic Resistance | 10~25 Hz ( X,Y,Z direction 2G/30 minutes) | ||
Cooling | Air cooling | ||
Protection | IP65 ( Front panel ) | ||
CE Certification | CE Certification: CE marked | ||
FCC Certification | FCC Class A |
